Yamaha RX-A4A AVENTAGE AV Receiver

• 7.2 Channel powerful surround sound with Zone2
• Wi-Fi, Bluetooth®, AirPlay 2, Spotify Connect and MusicCast multi-room audio
• SURROUND:AI automatically optimises the surround effect in real time
• Dolby Atmos® and DTS:X® with CINEMA DSP HD3
• YPAO™-R.S.C. with multi-point measurement, precision EQ and low frequency mode
• HDMI™ 7 in/3 out, 8K/60Hz, 4K/120Hz, HDR10+ via FW update
• Dedicated gaming function(ALLM,VRR,QMS,QFT) via FW update
• ESS SABRE ES9007S Premier Audio DAC for high performance conversion
• Voice control with Alexa and Google Assistant devices. *Availability varies by region

Amplifier Section:
Channel: 7.2
Rated Output Power (1kHz, 1ch driven): 135 W (8 ohms, 0.9% THD)
Rated Output Power (20Hz-20kHz, 2ch driven): 110 W (8 ohms, 0.06% THD)
Maximum Effective Output Power (1kHz, 1ch driven): 165 W (8 ohms, 10% THD)
High Slew Rate Amplifier: Yes

Surround Sound Processing:
Surround:AI: Yes
CINEMA DSP: Yes (HD3)
DSP Programs: 24
Dialog Level Adjustment: Yes
Virtual Presence Speaker: Yes
Virtual Surround Back Speaker: Yes
Dialogue Lift: Yes
SILENT CINEMA / Virtual CINEMA DSP: Yes
Dolby Atmos: Yes
Dolby Atmos Height Virtualizer: Yes
Dolby TrueHD: Yes
Dolby Digital Plus: Yes
Dolby Surround: Yes
DTS:X: Yes
DTS-HD Master Audio: Yes
Auro 3D: N/A

Audio Features:
File Format: MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz
Pure Direct: Yes
Compressed Music Enhancer: Yes
High-resolution Music Enhancer: Yes
YPAO multi-point measurement: Yes with R.S.C. (Reflected Sound Control) , 3D, 64-bit High Precision EQ Calculation and Angle Measurement
YPAO Volume: Yes
Adaptive DRC (Dynamic Range Control): Yes
Initial Volume & Maximum Volume Setting: Yes
A.R.T. Wedge: Yes
Bi-amp capability: Yes
Audio Delay: Yes (0-500 ms)
DA Converter: 384 kHz / 32-bit ESS Hyperstream DAC ES9007S

Video Features:
HDMI eARC: Yes
HDMI Audio Return Channel: Yes
HDMI Pass-through: 8K60AB, 4K120AB, 40GBPS (via future update)
HDMI Up-scaling: Yes, up to 8K (via firmware update)
HDMI Up-conversion: N/A
Dolby Vision: Yes
HDR 10+: Yes (via firmware update)
VRR/ALLM/QMS/QFT: Yes (via firmware update)
Video adjustment: N/A

Connectivity:
MusicCast Surround: Yes
HDMI Input/Output: 7 / 3 (HDMI2.1 / HDCP2.3)
HDMI CEC: Yes
USB Input: Yes
Network Port: Yes
Wi-Fi: Yes (2.4 / 5 GHz)
AirPlay 2: Yes
Bluetooth: Yes (SBC / AAC)
Front AV Input: USB
Digital Audio Input/Output: Optical: 2 / 0
Digital Audio Input/Output: Coaxial: 1 / 0
Analog Audio Input/Output: 4 / 0
Phono Input: Yes
XLR Terminal: N/A
Component Video Input/Output: N/A
Composite Video Input/Output: N/A
Preout: 7.2-ch
Headphone Output: 1

Tuner Section:
FM/AM Tuner: Yes (Availability varies by region.)
DAB Tuner: Yes (Availability varies by region.)

User Interface:
On-screen display: Graphical User Interface
SCENE: SCENE PLUS (8 sets)
App Control: Yes (iPhone / iPad / Android phone / tablet)
Web Browser Control: Yes
Remote Control Unit: Yes

Zone Control:
Zone 2 Audio Output: Preout / HDMI
Zone 3 Audio Output: N/A
Zone 4 Audio Output: N/A
Powered Zone: Zone 2
Zone Video Output: HDMI
Zone B Output: N/A
Zone GUI: N/A
RS-232C Interface: N/A
+12V Trigger Output: 2
Remote (IR) Input/Output: 1 / 1
Party Mode: Yes

General:
Standby Power Consumption (IR only): <0.4 W
Auto Power Standby: Yes
ECO mode: Yes
Dimensions (W x H x D): 435 W x 191 H x 442 D mm (with antenna up:435 W x 270 H x 442 D mm);17-1/8”W x 7-1/2”H x 17-3/8”D (with antenna up:17-1/8”W x 10-5/8”H x 17-3/8”D)
Weight: 16.2 kg; 35.7 lbs.
